Handheld XRF for RoHS application | TrueX 660

Handheld XRF for RoHS application

lien_he

  • The TrueX RoHS analyzer can be used to analyze the chemical composition of consumer products such as toys, clothing, footwear and electronic equipment in the field. It can quickly detect toxic elements such as lead Pb,Cd, Hg, Cr, Br and determine whether these consumer products comply with RoHS regulations. With the advantages of high sensitivity and high repeatability, it is the ideal choice for incoming material inspection, safety audit of finished products and storage products.

Advantages of TrueX 600/660:

  • The instrument is smaller in size and lighter in weight, so it is easy to carry.
  • The built-in omnidirectional environmental sensing system enables TrueX to sense changes in the surrounding environment in real time and automatically adjust parameters for element analysis under special conditions such as high and low temperature, dust, darkness and humidity.
  • Built-in DoubleBeam™ automatically detects samples in front of you for enhanced radiation safety and protection.
  • TrueX's new built-in net intensity fitting algorithm optimizes spectral resolution, enabling TrueX to have a low detection limit comparable to large laboratory equipment.
  • Built-in Ultrashort™ optical path design significantly improves the excitation effect of light elements Mg, Al, Si, S, P without nitrogen filling.
  • High-speed processing chips, advanced algorithms and efficient software combine to make instrument analysis faster.
  • 4.3-inch industrial resistance touch screen, compared with capacitor screen, has better backlight performance, can still be clearly visible under strong light in the field, and avoid the risk of removing gloves in special outdoor environment.
  • A single battery can work for about 8 hours. It supports hot swap and can be replaced in working state without shutting down. It can also monitor the remaining capacity of the battery in real time, and the battery complies with the air dangerous goods transport regulations.
  • Users can create customized professional reports, including company logo, company address, test results, spectrograph and other sample information (such as product description, origin, batch number, etc.).





Applications:

  • Restricted toxic elements in consumer products
  • Component analysis and brand identification of metal components/fasteners; Chlorine and bromine in polymer materials and plastics
  • Cadmium, lead and mercury in packaging materials
  • Cadmium, lead, bromine, mercury, chromium and other elements in electronic components, connectors, cables, etc.
  • Solder - the state of raw materials and the contents of tin, lead, copper, silver, bismuth, cadmium and other elements contained in the solder at different stages of use; High reliability electronic components contain adequate amounts of lead



Specifications:

Weight1.5KG
Size254mm×79mm×280mm(L×W×H)
Excitation source50kV/200μA upper limit, tube pressure tube flow can be adjusted freely, W/Ag/Rh target (optional)
Detector

Si-Pin etector/SDD detector

Display system

4.3 "industrial grade resistance touch screen

Automatically adjust display brightness according to external environment brightness

Data processing

Built-in 32GB storage

USB, can connect the device to the Internet, remote setting and maintenance of the instrument

Heat dissipationT-slot radiator
Security

Built-in DoubleBeam™ technology automatically senses samples ahead for enhanced radiation safety and protection

Waterproof, dustproof and shockproof carrying case

LANScientific special safety rope

Power system

Intelligent battery with MSBUS, real-time monitoring battery, spare battery can directly check the remaining capacity of the battery, the battery complies with the air dangerous goods transport regulations

A single battery can work for about 8 hours
