Features:
This equipment is used for thickness and hardness test of pait film surface such as paint, film etc., and measures by pressing at approx. 1kgf and moving on the surface putting a KS G2603 pencil lead at an angle of 45 degrees against the surface of samples (various painted area, decorated plywood, synthetic leather, coated surface etc)
Standard: JIS K5400, C3003, ASTM D2197
Specification:
| Model | ST-630P |
| Display | 2 line LCD digital display |
| Test speed | 10 ~ 500 mm/min |
| Load range | 100gf ~ 1000gf |
| Scratch angle | 45o (option 90o) |
| Specimen table size | 150 x 100 mm |
| Specimen size | 100 x 60 mm |
| Standard pencil | 17 ea (6B ~ 9H) |
| Dimensions | 500W x 150D x 280H mm |
| Power supply | AC 220V / 50,60 Hz |
| Weight | 20kg |
